SN74HC00DR SN74HC00D HC00 SOP14 Logic IC Chips
产品详情
SN74HC00DR SN74HC00D HC00 SOP14 logic IC chip original product
| attribute | the parameter value |
|---|---|
| product catalogs | logic gate |
| the attribution series of logic circuits | 74HC |
| logical type | with non-doors |
| number of circuits/components | 4 |
| number of inputs/number of bits per component | 2 |
| supply voltage | 2V ~ 6V |
| quiescent current (max) | 2μA |
| current - output high, low | 5.2mA,5.2mA |
| operating temperature | -40℃~85℃ |
| additional features | - |
| THE MAXIMUM PROPAGATION DELAY AT THE MAXIMUM CL FOR DIFFERENT VS | 15ns @ 6V,50pF |
| Logic Type | Number of Non-Gated |
| Circuits | 4 |
| Number of Inputs | 2 |
| Voltage - Supply | 2 V to 6 V |
| Current - Quiescent (Max) | 2μA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Logic Level - Low | 0.5 V to 1.8 V |
| Logic Level - High | 1.5 V ~ 4.2 V |
| Different V, Max Propagation Delay at CL | 15ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 85°C |
| Mount Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package/Housing | 14-SOIC (0.154", 3.90mm Wide) |
