HCPL-316J-500E 2.5A Gate Driver Optically Coupled 5000Vrms 1CH 16-SO
产品详情
HCPL-316J-500E 2.5A Gate Driver Optically Coupled 5000Vrms 1CH 16-SO
| TYPE | DESCRIBE |
|---|---|
| category | Isolator Isolator - Gate Driver |
| manufacturer | Broadcom Limited |
| series | - |
| product status | in stock |
| technology | Optical coupling |
| number of channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 15kV/µs |
| Propagation delay tpLH / tpHL (max) | 500ns,500ns |
| Pulse width distortion (max) | 300ns |
| Rise/Fall Time (Typical) | 100ns,100ns |
| Current - Output High, Low | 2A,2A |
| Current - Peak Output | 2.5A |
| Voltage - Forward (Vf) (typ) | - |
| Voltage - Output Power | 15V ~ 30V |
| Operating temperature | -40°C ~ 100°C |
| installation type | Surface Mount Type |
| Package/Enclosure | 16-SOIC (0.295", 7.50mm wide) |
| Supplier Device Packaging | 16-SO |
| Certification body | CSA , IEC / EN / DIN , UR |
| Basic product number | HCPL-316 |
